??:? ??? / ?? ?? / ???? ?? / ?? ?? ??? ?? ???? ?? DIN c.s RS gate valve Z41W-16C

?? ?? ??? ?? ???? ?? DIN c.s RS gate valve Z41W-16C

?? ??? ???????? ?? ?

?? ?? ??? ?? ???? ?? DIN c.s RS gate valve Z41W-16C

?? ??



?? ??

?? ?? DN5065801001251502002503003504004505006007008009001000
? ?? L RF/BW150170180190200210230250270290310330350390430470510550
??? W160180180200220220250300350400450450450450500600--
??? H350420500520610700900105012001400158017001900230026003200--
全开高 H14154955806207208401100130015401750198021502450300035004100--
?? kg1722273853681081602202753904875608501250183022903700

?? ??

1. ?? ?? DIN EN 13709:2003

2. ?? ?? ?? DIN EN 558-1:1995

3. ?? ??? ?? DIN EN 1092-1:2002

4. ?? ?? ?? ?? DIN EN 12627

5. ?? ? ?? ??

?? ?? ???

No.Parts NameMaterials
1BodyGS-C25/1.0619+13CrCF8/1.4301CF8M/1.4408
2DiscGS-C25+13CrSS304SS316
3StemX20Cr13SS304SS316
4GasketGraphite+SSGraphite+SSGraphite+SS
5BoltA193 B7A193 B8A193 B8M
6NutA194 2HA194 8A194 8M
7BonneGS-C25/1.0619CF8/1.4301CF8M/1.4408
8PackingGraphiteGraphiteGraphite
9PinSS410SS410SS410
10GlandA105SS304SS316
11Gland flangeWCBSS304SS316
12BoltA193 B7A193 B8A193 B8M
13NutA194 2HA194 8A194 8M
14Grease NippleH2H2H2
15Stem nutDuctile ironCopper alloyCopper alloy
16Bearing coverA105SS304SS316
17Hand wheelSteelSteelSteel
18Lock nutSS410SS410SS410


?? ??

????????

??? ?? ?? ? ?? ?? ?? ??? ??? ??? ???? ??????.
